Ultrasonic Dust Removal System
Application
Providing fast and efficient ultrasonic dust removal solutions for fields such as battery coating, semiconductor devices, and glass substrates.
Features
Low maintenance costs
Not in contact or damaging the material surface
No secondary pollution
High dust particle removal rate
Technical Parameter
Dust removal head size
100-2000 ㎜
Chamber pressure
4-5 kPa
Negative pressure port pressure
-4~-1 kPa
Working distance
≤5 ㎜
Control cabinet size
800*850*2000 ㎜
Power supply
380V
Blowing rate
＞600 m³/h
Filtration efficiency
99%(Accuracy=0.3μm)
Working environment
10-30℃, 45-70% RH, no frost formation
